Form QTC3-NM1
Issue date: 12/19/2023
Section 5: Technical data
Table 13: Wiring lugs
QTC3 Global market Single point
supply
terminal block
Molded case switch
single point supply
Molded case circuit
breaker single point
supply
V Hz Installed lug Installed lug Alternate lug Installed lug Alternate lug
3040T
208 60 (1) # 6 - 500 — — (1) 4 - 300 —
230 60 (1) # 6 - 500 — — (1) 4 - 300 —
380 60 (1) # 6 - 500 — — (1) 4 - 300 —
460 60 (1) # 6 - 500 — — (1) 4 - 300 —
575 60 (1) # 6 - 500 — — (1) 4 - 300 —
3050T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
380 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
460 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3055T
208 60 (1) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
230 60 (1) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
380 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
460 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3060T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
380 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 6 - 350 —
460 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3070T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
380 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
460 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3075T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
380 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (1) 6 - 350 —
460 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3079T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500
380 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (2) 3/0 - 250 (1) 250 - 500
460 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3085T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
380 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
460 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3090T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
380 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
460 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 6 - 350 —
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
Note: Alternate lugs are available in the panel for field electricians and contractors, if other lug arrangements are
necessary for the installed lugs on the non-fused disconnect switch and circuit breaker panels.
