Quantech QTC3040T User Manual

Quantech
71
Section 5: Technical data
Form QTC3-NM1
Issue date: 12/19/2023
55
Table 13: Wiring lugs, continued
QTC3 Global market Single point
supply
terminal block
Molded case switch
single point supply
Molded case circuit
breaker single point
supply
V Hz Installed lug Installed lug Alternate lug Installed lug Alternate lug
3095T/3100T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
380 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
460 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
575 60 (1) # 6 - 500 (1) 6 - 350 — (1) 6 - 350 —
3110T/3120T
208 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
230 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
380 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
400/460 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
575 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
3125T
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
230 60 — — — — —
380 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
400/460 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
575 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
3129T
208 60 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
230 60 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
380 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
460 60 (2) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
575 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
3140T/ 3140T/
3150T
208 60 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
230 60 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
380 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
400/460 60 (2) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
575 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
3160T/ 3170T/
3205T
208 60 (4) 4/0 - 500 (4) 4/0 - 500 — (3) 2/0 - 400 (2) 250 - 500
230 60 (4) 4/0 - 500 (4) 4/0 - 500 — (3) 2/0 - 400 (2) 250 - 500
380 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
460 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
575 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
3225T
208 60 (4) 4/0 - 500 (4) 4/0 - 500 — (4) 4/0 - 500 —
230 60 (4) 4/0 - 500 (4) 4/0 - 500 — (4) 4/0 - 500 —
460 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
575 60 (2) # 6 - 500 — — (2) 3/0 - 250 (1) 250 - 500
Note: Alternate lugs are provided in the panel for field electricians and contractors, if other lug arrangements are
necessary for the installed lugs on the non-fused disconnect switch and circuit breaker panels.
