Quantech QTC3040T User Manual

Quantech
60
Form QTC3-NM1
Issue date: 12/19/2023
Section 5: Technical data
Table 11: Electrical data without pumps, R-410A, continued
QTC3 V Hz MCA Min. N/F
disc SW
Min. dual
elem. fuse
and CB
Max. dual
elem. CB
System 1
Compr. 1 Compr. 2 Compr. 3 Std. ow fans
RLA LRA RLA LRA RLA LRA Qty. FLA LRA
3090T
208 60 406 600 450 450 57.7 284 57.7 284 57.7 284 3 7.6 44
230 60 405 600 450 450 57.7 330 57.7 330 57.7 330 3 7.4 37
380 60 220 400 250 250 30.9 192 30.9 192 30.9 192 3 4.5 23.1
460 60 192 250 225 225 26.9 180 26.9 180 26.9 180 3 4 19
575 60 152 200 150 150 21.5 132 21.5 132 21.5 132 3 2.9 15.3
3095T
208 60 450 600 500 500 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 449 600 500 500 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 260 400 300 300 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 220 400 250 250 26.9 180 26.9 180 26.9 180 2 4 19
575 60 175 250 200 200 21.5 132 21.5 132 21.5 132 2 2.9 15.3
3100T
208 60 458 600 500 500 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 456 600 500 500 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 264 400 300 300 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 224 400 250 250 26.9 180 26.9 180 26.9 180 2 4 19
575 60 178 250 200 200 21.5 132 21.5 132 21.5 132 2 2.9 15.3
3110T
208 60 497 800 600 600 106.2 523 106.2 523
— —
3 7.6 44
230 60 496 800 600 600 106.2 578 106.2 578 — — 3 7.4 37
380 60 300 400 350 350 64.3 355 64.3 355 — — 3 4.5 23.1
460 60 250 400 300 300 53.1 290 53.1 290 — — 3 4 19
575 60 198 250 225 225 42.5 255 42.5 255
— —
3 2.9 15.3
3120T
208 60 512 800 600 600 106.2 523 106.2 523
— —
4 7.6 44
230 60 511 800 600 600 106.2 578 106.2 578 — — 4 7.4 37
380 60 309 400 350 350 64.3 355 64.3 355 — — 4 4.5 23.1
460 60 258 400 300 300 53.1 290 53.1 290 — — 4 4 19
575 60 204 250 225 225 42.5 255 42.5 255
— —
4 2.9 15.3
3125T
208 60 579 800 600 600 106.2 523 106.2 523 106.2 523 4 7.6 44
230 60 577 800 600 600 106.2 578 106.2 578 106.2 578 4 7.4 37
380 60 338 600 400 400 64.3 355 64.3 355 64.3 355 4 4.5 23.1
460 60 285 400 300 300 53.1 290 53.1 290 53.1 290 4 4 19
575 60 226 400 250 250 42.5 255 42.5 255 42.5 255 4 2.9 15.3
3130T
208 60 555 800 600 600 85.1 394 85.1 394 85.1 394 4 7.6 44
230 60 553 800 600 600 85.1 436 85.1 436 85.1 436 4 7.4 37
380 60 329 400 350 350 49.3 252 49.3 252 49.3 252 4 4.5 23.1
460 60 274 400 300 300 40.7 212 40.7 212 40.7 212 4 4 19
575 60 217 400 250 250 32.6 168 32.6 168 32.6 168 4 2.9 15.3
3140T
208 60 618 800 700 700 106.2 523 106.2 523 106.2 523 4 7.6 44
230 60 617 800 700 700 106.2 578 106.2 578 106.2 578 4 7.4 37
380 60 374 600 400 400 64.3 355 64.3 355 64.3 355 4 4.5 23.1
460 60 311 400 350 350 53.1 290 53.1 290 53.1 290 4 4 19
575 60 246 400 300 300 42.5 255 42.5 255 42.5 255 4 2.9 15.3
3150T
208 60 634 800 700 700 106.2 523 106.2 523 106.2 523 6 7.6 44
230 60 632 800 700 700 106.2 578 106.2 578 106.2 578 6 7.4 37
380 60 383 600 400 400 64.3 355 64.3 355 64.3 355 6 4.5 23.1
460 60 319 400 350 350 53.1 290 53.1 290 53.1 290 6 4 19
575 60 252 400 300 300 42.5 255 42.5 255 42.5 255 6 2.9 15.3
Notes:
• Reference PIN 59 for pump models.
• Use this table along with Table 9 on page 58 to determine electrical data of the unit plus the pump.
• Does not include the control transformer.
