Quantech QTC3040T User Manual

Quantech
26
Form QTC3-NM1
Issue date: 12/19/2023
Section 1: General chiller information and safety
Table 2: Complete PIN number description, continued
Feature Feature description Option Option description
PFC
Power Factor Capacitor
(PIN 19)
X No Power Capacitor required
C Power Capacitor required
Q Special Power Capacitor required
AMB
Ambient Kits
(PIN 20)
H High Ambient Kit Standard (factory)
A Both Low/High Ambient Kit required (factory)
B Both Low/High Ambient Kit w/Sunshield (factory)
S High Ambient Kit w/Sunshield (factory)
Q Special Ambient Kit required
BAS
Bas Reset/O󰀨set
(PIN 21)
X No Selection
L LON E-Link
S SC-Equip Board
Q Special Quote
LCD
Language
(PIN 22)
X English
S Spanish
C Chinese (Simplied) (Not Applicable to eLogia)
E
English with Chinese Displayed Board
(Not Applicable to eLogia)
F French
G German
I Italian
RDOUT
Readout Kits
(PIN 23)
B Both Discharge & Suction Pressure Transducer Readout required
Q Special Pressure Readout required
SAFETY
Safety Codes
(PIN 24)
C European Saftey Code (CE)
G China Safety Code (GB) (Not Applicable to eLogia)
L N American Safety Code (cUL/cETL)
SENSOR PIN 25
X X
Q Special Quote
PUMP
Motor Current Module
(PIN 26)
C Motor Current Module
Q Special Quote
REMOTE
Remote Panel
(PIN 27)
X No Remote Panel required
Q Special Remote Panel required
SEQ
Sequence Kit
(PIN 28)
X No Sequence Kit required
Q Special Sequence Kit required
TEMP
Leaving Water Temp
(PIN 29,30)
NUM Leaving Water Temp = Temp/Num Deg.
CHICAGO
Chicago Code Kit
(PIN 31)
X No Chicago Code Kit required
B Both Chicago Code & Serv Isolation
C Chicago Code Kit required
G Both Suction Service Valve and Dual Relief Valve (Europe only)
R Dual Relief Valves no Suction Service Valve (Europe only)
S Service Isolation Valves
Q Special Chicago Code Kit required
VALVES
Valves
(PIN 32)
X Standard Valves Required
E Electronic Expansion Valve
Q Special Optional Valves Required
HGBP
Hot Gas Bypass
(PIN 33)
X No Hot Gas Bypass required
1 Hot Gas Bypass required - 1 circuit
Q Special Hot Gas Bypass required
