Quantech QWC3050T-200T User Manual

FORM QWC3-NM1
ISSUE DATE: 11/20/2020
SECTION 5 – TECHNICAL DATA
QUANTECH
102
ENGLISH
Size D H L T W BC CS MBD
ND-C
2 9/16
(65.1)
2 3/ 4
(69.9)
5 1/ 2
(139.7)
1/ 4
(6.4)
2 5/16
(58.7)
4 1/80
(101.9)
1/2- 13 x 1” 1/ 2 “
ND-D
3 3/ 8
(85.7)
2 3/ 4
(69.9)
6 1/ 4
(158.8)
5/16
(7.9)
4
(101.6)
5
(127)
1/2- 13 x 1” 1/ 2 “
ND-DS
4 1/ 2
(114.3)
4 3/ 4
(120.7)
7 3/ 8
(187.3)
1/ 4
(6.4)
5 1/80
(127.3)
6 1/80
(152.7)
1/2- 13 x 1” 1/ 2 “
Weight Range (lbs) Weight Range (kg) Model Number Color
Up to 751 lbs Up to 341 kg ND-C Yellow
751 to 1651 lbs 341 to 749 kg ND-D Yellow
1651 to 3226 lbs 749 to 1463 kg ND-DS Yellow
Top & Bottom -
Steel Plates.
Neoprene covered
to prevent corosion
and provide friction.
“CS” CAP SCREW
“MBD” MAXIUM
BOLT DIAMETER
D
H
W
T
BC
L
Mod Mason ND.eps
ELASTOMETRIC ISOLATOR CROSS-REFERENCE
Units shipped before June 15, 2008
