Quantum FIREBALL PLUS AS 10.2 User Manual

ATA Bus Interface and ATA Commands
Quantum Fireball Plus AS 10.2/20.5/30.0/40.0/60.0 GB AT 6-41
6.7.9.2
6.7.9.26.7.9.2
6.7.9.2 SMART ENABLE OPERATIONS
SMART ENABLE OPERATIONSSMART ENABLE OPERATIONS
SMART ENABLE OPERATIONS
COMMAND CODE - B0h
TYPE - Optional - SMART Feature set. If the SMART feature set is implemented,
this command shall be implemented.
PROTOCOL - Non-data command
INPUTS - The Features register shall be set to D8h. The Cylinder Low register shall
be set to 4Fh. The Cylinder High register shall be set to C2h.
NORMAL OUTPUTS - None
ERROR OUTPUTS - If the device does not support this command or if the values
in the Features, Cylinder Low or Cylinder High registers are invalid, an Aborted
command error is posted.
PREREQUISITES -DRDY set equal to one.
DESCRIPTION - This command enables access to all SMART capabilities within
the device. Prior to receipt of this command attribute values are neither monitored
nor saved by the device. The state of SMART (either enabled or disabled) will be
preserved by the device across power cycles. Once enabled, the receipt of
subsequent SMART ENABLE OPERATIONS commands shall not affect any of the
attribute values.
Upon receipt of this command from the host, the device sets BSY, enables SMART
capabilities and functions, clears BSY and asserts INTRQ.
Register
RegisterRegister
Register 7
77
76
66
65
55
54
44
43
33
32
22
21
11
10
00
0
Features D8h
Sector Count
Sector Number
Cylinder Low 4Fh
Cylinder High C2h
Device/Head 1 1 D
Command B0h
Register
RegisterRegister
Register 7
77
76
66
65
55
54
44
43
33
32
22
21
11
10
00
0
Error na UNC na IDNF na ABRT na na
Sector Count na
Sector Number na
Cylinder Low na
Cylinder High na
Device/Head obs na obs DEV na
Status BSY DRDY DF na DRQ na na ERR
