Quatech Serial Device Server

Installing the device drivers Quatech SDS User’s Manual
Figure 17 - TCP/IP Network Configuration Parameters screen
Step Procedure Description
 Step 22 Press the Next button to continue. The Rerun network connectivity test pop-
up box displays.
Continue with □ Step 23.
Figure 18 - Rerun network connectivity test pop-up box
Step Procedure Description
 Step 23 Press the OK button to continue. The Network Connectivity Test screen
displays. Continue with □ Step 24.
Figure 19 shows the Rerun
network connectivity test pop-
up box.
Figure 18 shows the TCP/IP
network configuration parameters
including the following:
¾ Address type
¾ IP Address
¾ Subnet mask
¾ Default gateway
Page 24 940-0183-153 July 2005
