Quatech SDS User’s Manual Installing the device drivers
Figure 34 - Locate the Serial Device Server using direct discovery screen
Figure 35 explains how to
connect the SDS to your
computer for location and
configuration purposes.
Step Procedure Description
Step 43 Connect the Ethernet port on your SDS to
the Network Interface Connection (NIC)
on your computer. Either a crossover
patch cable or a “straight through” cable
will work.
Continue with □ Step 44.
Step 44 Connect power to the SDS and confirm
that it is ready to proceed.
Press Next to continue.
The Status LED should glow green.
The Search network for Serial Device
Drivers screen displays.
Go to
□ Step 10.
July 2005 940-0183-153 Page 37
