Installing the device drivers Quatech SDS User’s Manual
Figure 26 - Internet Protocol (TCP/IP) Properties dialog box
Figure 27 shows the current
configuration parameters for
the SDS. You can change these
parameters by keying in the
desired values.
Step Procedure Description
Step 32 The Internet Protocol (TCP/IP) Properties
dialog box lets you change the SDS’
configuration so that it can operate in its
permanent location.
Select one of the following options:
¾ Use the following static IP address.
¾ Obtain an IP address automatically
from the DHCP server.
If you are not sure of the configuration
parameters, consult your system
administrator.
Note: We recommend that you use a static
IP address to ensure reliable operation.
Continue with □ Step 33.
Go to □ Step 34.
Step 33 Key in any necessary changes to the:
¾ IP address,
¾ Subnet mask, and
¾ Default gateway.
Your system administrator can provide
you with specific parameters.
Step 34 Press Send to send your changes to the
SDS.
The Restart confirmation pop-up box
displays. Continue with □ Step 35.
Page 32 940-0183-153 July 2005
