Appendix A Quatech SDS User’s Manual
1- and 2-port models: All LEDs have the same definitions as above and are located as
indicated below:
¾ Power – top cover
¾ Link – left side of Ethernet connector
¾ Speed – right side of Ethernet connector
¾ Data – next to DB-9 serial port(s)
¾ Status – next to power jack
Power supply DC input, with AC Adapters provided for 100VAC–240VAC, 50Hz–
60Hz, Autosensing.
+5V, 2A (10W) max
Environment Operating: 0° C to 70° C
Storage: –40° C to 70° C
Relative Humidity: 10% to 90% non-condensing
Certifications FCC, CE, IC
Page 88 940-0183-153 July 2005
