GL200 Manage Tool User Guide
TRACGL200MT002 - 20 -
3.2. Device Configuration in Professional Setting Mode
The manage tool is developed based on the @Track Air Interface Protocol. Please refer to “GL200
@Track Air Interface Protocol” for detail.
Following is a general procedure to configure GL200 with manage tool.
3.2.1 Set the parameters of Bearer Setting Information
Step_1: Select “Bearer Setting Information”, after that the parameters of GTBSI show in
Command Operation Space.
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200
through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL200 and edit based on them.
Step_4: Set APN parameters. Please refer to “GL200 @Track Air Interface Protocol” for the
meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTBSI to GL200.
Step_1
Step_4
Step_2
Step_3
Step_5
