Queclink GL200 - Set the Parameters of Time Adjustment

GL200 Manage Tool User Guide
TRACGL200MT002 - 25 -
Command Operation Space.
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200
through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL200 and edit based on them
Step_4: Set the Software Protocol Watchdog parameters. Please refer to “GL200 @Track Air
Interface Protocol” for the meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTDOG to GL200.
3.2.7 Set the parameters of Time Adjustment
Step_1: Select “Time Adjustment”, after that the parameters of GTTMA show in Command
Operation Space.
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200
through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL200 and edit based on them.
Step_4: Set the Time Adjustment parameters. Please refer to “GL200 @Track Air Interface
Protocol” for the meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTTMA to GL200.
Step_1
Step_2
Step_3
Step_5
Step_4
