Queclink GL200 - Backend Server Register Information Configuration

GL200 Manage Tool User Guide
TRACGL200MT002 - 21 -
3.2.2 Set the parameters of Backend Server Register Information
Step_1: Select “Backend Server Register Information”, after that the parameters of GTSRI show
in Command Operation Space.
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200
through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL200 and edit based on them
Step_4: Set Backend Server Register Information parameters. Please refer to “GL200 @Track Air
Interface Protocol” for the meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTSRI to GL200.
Step_1
Step_4
Step_2
Step_3
Step_5
