Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 9 / 56
2 Product Concept
2.1. General Description
EP06 is a series of LTE-A/UMTS/HSPA+ wireless communication modules with receive diversity. It
provides data connectivity on LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA
networks with PCI Express Mini Card 1.2 standard interface.
EP06 series supports embedded operating systems such as Windows CE, Linux and Android, and also
provides GNSS
1)
and voice functionality
2)
to meet your specific application demands. EP06 series
contains two variants: EP06-E and EP06-A. You can select a dedicated type based on your application
regions or target operators.
The following table shows the frequency bands and GNSS types of EP06 series.
Table 1: Frequency Bands and GNSS Types of EP06 Series
Mode
EP06-E
EP06-A
LTE-FDD
(with Rx-diversity)
B1/B3/B5/B7/B8/B20/B28/B32
3)
B2/B4/B5/B7/B12/B13/B25/B26/
B29
3)
/B30/B66
LTE-TDD
(with Rx-diversity)
B38/B40/B41
Not supported
2 × CA
B1+B1/B5/B8/B20/B28;
B3+B3/B5/B7/B8/B20/B28;
B7+B5/B7/B8/B20/B28;
B20+B32
3)
;
B38+B38;
B40+B40;
B41+B41
B2+B2/B5/B12/B13/B29
3)
;
B4+B4/B5/B12/B13/B29
3)
;
B7+B5/B7/B12/B26;
B25+B5/B12/B25/B26;
B30+B5/B12/B29
4)
;
B66+B5/B12/B13/B29
4)
/B66
WCDMA
(with Rx-diversity)
B1/B3/B5/B8
B2/B4/B5
GNSS
GPS, GLONASS,
BeiDou/Compass, Galileo, QZSS
GPS, GLONASS,
BeiDou/Compass, Galileo, QZSS
QZSS
