LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 54 / 56
Figure 22: Bottom View of the Module
These are renderings of the module. For authentic appearance, please refer to the module received from
Quectel.
7.4. Packaging
The module is packaged in a tray and each tray contains 10 modules. The smallest package contains 100
modules.
NOTE
