Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 40 / 56
6.3. Power Supply Requirements
The typical input voltage of the module is 3.3 V, as specified by PCI Express Mini CEM Specifications 1.2.
And the power supply of the module should be able to provide sufficient current 2 A at least. The following
table shows the power supply requirements of the module.
Table 22: Power Supply Requirements of EP06 Series
6.4. RF Characteristics
The following tables show the RF output power and receiving sensitivity of the module.
Table 23: RF Output Power
Table 24: EP06-E Conducted RF Receiving Sensitivity
Parameter
Description
Min.
Typ.
Max.
Unit
VCC
Power Supply
3.1
3.3
4.4
V
Frequency
Max.
Min.
WCDMA bands
24 dBm +1/-3 dB
< -50 dBm
LTE FDD bands
23 dBm ±2 dB
< -40 dBm
LTE TDD bands
23 dBm ±2 dB
< -40 dBm
Frequency
Primary (Typ.)
Diversity (Typ.)
SIMO
1)
(Typ.)
SIMO
2)
(Worst Case)
WCDMA B1
-109.5 dBm
-107.5 dBm
/
-106.7 dBm
WCDMA B3
-108.5 dBm
-108.0 dBm
/
-103.7 dBm
WCDMA B5
-108.5 dBm
-109.0 dBm
/
-104.7 dBm
WCDMA B8
-109.5 dBm
-109.5 dBm
/
-103.7 dBm
LTE-FDD B1 (10 MHz)
-98.0 dBm
-96.0 dBm
-99.5 dBm
-96.3 dBm
