Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 35 / 56
5.2. GNSS Antenna Connector
The following tables show details of GNSS antenna connector and the frequency specification of GNSS
antenna.
Table 18: Description of GNSS Antenna Connector
Table 19: GNSS Frequency
5.3. Antenna Connectors and Mating Plugs
The dimensions of the antenna connectors are shown as below.
Connector
I/O
Description
Comment
D2/G
AI
GNSS antenna connector
50 Ω impedance
Type
Frequency
Unit
GPS
1575.42 ±1.023
MHz
GLONASS
1597.5–1605.8
MHz
Galileo
1575.42 ±2.046
MHz
BeiDou
1561.098 ±2.046
MHz
QZSS
1575.42
MHz
