3.8. Tunable Antenna Control Interface*
ANTCTL[0:3] signals are used for tunable antenna control and should be routed to an appropriate
antenna control circuitry.
More details about the interface will be added in the future version of the document.
Table 13: Pin Definition of Tunable Antenna Control Interface*
“*” means under development.
Pin Name
Pin No.
I/O
Description
Comment
ANTCTL0
3
DO
Tunable antenna control
1.8 V power domain
ANTCTL1
5
DO
Tunable antenna control
1.8 V power domain
ANTCTL2
44
DO
Tunable antenna control
1.8 V power domain
ANTCTL3
46
DO
Tunable antenna control
1.8 V power domain
