Quectel EP06 Series - Key Features

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 10 / 56
1.
1)
GNSS function is optional.
2.
2)
EP06 series contains Telematics version and Data-only version. Telematics version supports
voice and data functions, while Data-only version only supports data function.
3.
3)
LTE-FDD B29 and B32 support Rx only, and in 2 × CA they are only for secondary component
carrier.
EP06 series can be applied in the following fields:
 Rugged Tablet PC
 Remote Monitor System
 Vehicle System
 Wireless POS System
 Smart Metering System
 Wireless Router and Switch
 Other Wireless Terminal Devices
2.2. Key Features
The following table describes the detailed features of EP06 series.
Table 2: Key Features of EP06 Series
Feature
Details
Functional Interface
PCI Express Mini Card 1.2 Standard Interface
Power Supply
Supply voltage: 3.1–4.4 V
Typical supply voltage: 3.3 V
Transmitting Power
Class 3 (23 dBm ±2 dB) for LTE-FDD bands
Class 3 (23 dBm ±2 dB) for LTE-TDD bands
Class 3 (24 dBm +1/-3 dB) for WCDMA bands
LTE Features
Support up to LTE Cat 6
Support 1.4 to 40 MHz (DL 2 × CA) RF bandwidth
Support 2 × 2 MIMO in DL direction
FDD: Max 300 Mbps (DL)/50 Mbps (UL)
TDD: Max 226 Mbps (DL)/28 Mbps (UL)
UMTS Features
Support 3GPP R8 DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA
Support QPSK, 16-QAM and 64-QAM modulation
DC-HSDPA: Max 42 Mbps
NOTES
