Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 43 / 56
Table 27: Electrostatic Discharge Characteristics (Temperature: 25 °C, Humidity: 45%)
6.7. Current Consumption
The following table shows the current consumption of EP06-E.
Table 28: EP06-E Current Consumption
Tested Points
Contact Discharge
Air Discharge
Unit
VBAT, GND
±5
±10
kV
Antenna Interfaces
±4
±8
kV
Other Interfaces
±0.5
±1
kV
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
Sleep state
AT+CFUN=0 (USB disconnected)
1.69
mA
WCDMA PF=64 (USB disconnected)
2.65
mA
WCDMA PF=128 (USB disconnected)
2.69
mA
WCDMA PF=256 (USB disconnected)
2.41
mA
WCDMA PF=512 (USB disconnected)
2.66
mA
LTE-FDD PF=32 (USB disconnected)
3.06
mA
LTE-FDD PF=64 (USB disconnected)
3.26
mA
LTE-FDD PF=128 (USB disconnected)
2.58
mA
LTE-FDD PF=256 (USB disconnected)
2.26
mA
LTE-TDD PF=32 (USB disconnected)
3.1
mA
LTE-TDD PF=64 (USB disconnected)
3.3
mA
LTE-TDD PF=128 (USB disconnected)
2.63
mA
LTE-TDD PF=256 (USB disconnected)
2.29
mA
Idle state
WCDMA PF=64 (USB disconnected)
24
mA
