Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 41 / 56
Table 25: EP06-A Conducted RF Receiving Sensitivity
LTE-FDD B3 (10 MHz)
-97.5 dBm
-97.5 dBm
-100.0 dBm
-93.3 dBm
LTE-FDD B5 (10 MHz)
-97.0 dBm
-98.5 dBm
-99.5 dBm
-94.3 dBm
LTE-FDD B7 (10 MHz)
-96.0 dBm
-96.0 dBm
-98.5 dBm
-94.3 dBm
LTE-FDD B8 (10 MHz)
-98.5 dBm
-98.0 dBm
-101.0 dBm
-93.3 dBm
LTE-FDD B20 (10 MHz)
-97.5 dBm
-99.0 dBm
-101.0 dBm
-93.3 dBm
LTE-FDD B28 (10 MHz)
-96.0 dBm
-98.0 dBm
-99.0 dBm
-94.8 dBm
LTE-TDD B38 (10 MHz)
-96.5 dBm
-96.0 dBm
-98.5 dBm
-96.3 dBm
LTE-TDD B40 (10 MHz)
-96.5 dBm
-97.0 dBm
-99.5 dBm
-96.3 dBm
LTE-TDD B41 (10 MHz)
-96.0 dBm
-96.0 dBm
-98.5 dBm
-94.3 dBm
Frequency
Primary (Typ.)
Diversity (Typ.)
SIMO
1)
(Typ.)
SIMO
2)
(Worst Case)
WCDMA B2
-109.5 dBm
-108.5 dBm
/
-106.7 dBm
WCDMA B4
-109 dBm
-108.5 dBm
/
-103.7 dBm
WCDMA B5
-109.5 dBm
-110 dBm
/
-104.7 dBm
LTE-FDD B2 (10 MHz)
-98.2 dBm
-97.7 dBm
-100.7 dBm
-94.3 dBm
LTE-FDD B4 (10 MHz)
-97.7 dBm
-97.8 dBm
-100.2 dBm
-96.3 dBm
LTE-FDD B5 (10 MHz)
-98.0 dBm
-98.1 dBm
-100.9 dBm
-94.3 dBm
LTE-FDD B7 (10 MHz)
-96.2 dBm
-97 dBm
-98.2 dBm
-94.3 dBm
LTE-FDD B12 (10 MHz)
-97.2 dBm
-97.8 dBm
-101.7 dBm
-93.3 dBm
LTE-FDD B13 (10 MHz)
-97.7 dBm
-98.1 dBm
-100.7 dBm
-93.3 dBm
LTE-FDD B25 (10 MHz)
-98.8 dBm
-98.5 dBm
-100.5 dBm
-92.8 dBm
LTE-TDD B26 (10 MHz)
-98.5 dBm
-99.2 dBm
-101.8 dBm
-93.8 dBm
LTE-TDD B30 (10 MHz)
-96.9 dBm
-97.8 dBm
-99.2 dBm
-95.3 dBm
LTE-TDD B66 (10 MHz)
-98.1 dBm
-97.9 dBm
-100.6 dBm
-95.8 dBm
