1)
EP06 series module supports only passive GNSS antenna. If an active antenna is intended to be used,
then it is necessary to design an external power supply circuit for the GNSS antenna. However, when
LTE B13 or B14 is supported, it is recommended to use a passive GNSS antenna as the use of active
antenna may generate harmonics which will affect the GNSS performance.
LTE B5/B8/B12/B13/B18/B19/B20/B26/B28/B29)
Cable Insertion Loss: <1.5 dB
(WCDMA B1/B2/B3/B4/B9, LTE B1/B2/B3/B4/B25/B32/B39/B66)
Cable Insertion Loss: < 2 dB
(LTE B7/B38/B40/B41/B30)
NOTE

Quectel EP06 Series Specifications

General

Brand	Quectel
Model	EP06 Series
Category	Control Unit
Language	English
