Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 48 / 56
Table 31: GNSS Current Consumption of EP06-A
LTE-FDD B7+B5 @ 20.67 dBm
909.2
mA
LTE-FDD B7+B7 @ 20.63 dBm
903.5
mA
LTE-FDD B7+B12 @ 20.47 dBm
915.8
mA
LTE-FDD B7+B26 @ 20.55 dBm
938
mA
LTE-FDD B25+B5 @ 20.94 dBm
695.4
mA
LTE-FDD B25+B12 @ 20.55 dBm
697.5
mA
LTE-FDD B25+B25 @ 20.54 dBm
762.6
mA
LTE-FDD B25+B26 @ 21.06 dBm
721.4
mA
LTE-FDD B30+B5 @ 20.56 dBm
794.4
mA
LTE-FDD B30+B12 @ 20.43 dBm
799.4
mA
LTE-FDD B30+B29 @ 20.31 dBm
806.1
mA
LTE-FDD B66+B5 @ 20.06 dBm
732.9
mA
LTE-FDD B66+B12 @ 20.03 dBm
734
mA
LTE-FDD B66+B29 @ 20.05 dBm
736.1
mA
LTE-FDD B66+B66 @ 19.93 dBm
801.7
mA
LTE-FDD B66+B13 @ 20.03 dBm
739.7
mA
WCDMA
voice call
WCDMA B2 CH9400 @ 24.2 dBm
608.1
mA
WCDMA B4 CH1412 @ 23.8 dBm
720.8
mA
WCDMA B5 CH4407 @ 23.5 dBm
619.6
mA
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
(GNSS)
Searching
(AT+CFUN=0)
Cold state @ Passive Antenna
59.5
mA
Lost state @ Passive Antenna
54.4
mA
Tracking
(AT+CFUN=0)
Instrument environment
28.5
mA
