Section 6: From the left to the right ,you will seevideo quality/fluency/ full screen/1-
window/4-window/6-window/8-window/9-window/13-window/16-window/20-window/25-
window/36-window.. You can set video fluency and real-time feature priority.
Section 7: PTZ operation panel. Please refer to chapter 7.5 for detailed information.
Section 8: Image setup and alarm setup. Please refer to chapter 7.6 for detailed information.
Section 9: Zero-channel encoding mode option.
Figure 7-9
7.4 Real-time Monitor
In section 2, left click the channel name you want to view, you will seethe corresponding video in
current window.
On the top left corner, you can view device IP(10.10.6.129), channel number(1), network monitor
bit stream(2466Kbps) and stream type (M=main stream. S=Sub stream). See Figure 7-10.
Figure 7-10
