Figure 5-10
Figure 5-11
5.3.3 Schedule
Please refer to chapter 4.5 schedule.
5.3.4 Network
Here is for you to input network information.
The single network adapter interface is shown as in Figure 5-12.
IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP
address format and you can access via them.
MAC address: The host in the LAN can get a unique MAC address. It is for you to access in the
LAN. It is read-only.
IP address: Here you can use up/down button () or input the corresponding number to
input IP address. Then you can set the corresponding subnet mask the default gateway.
Subnet prefix: The input value ranges from 0 to 128. This is to mark a specified network
MAC address. Usually it includes an organization of multiple-level.
