Figure 4-40
Note:
Preset, tour and pattern all need the value to be the control parameter. You can define it as
you require.
You need to refer to your speed dome user’s manual for Aux definition. In some cases, it
can be used for special process.
The following setups are usually operated in the X332H332H332HFigure 4-36, Figure 4-39 and Figure 4-40.
4.9.1Preset Setup
In Figure 4-36, use the eight direction arrows to adjust camera to the proper position.
In Figure 4-39, click preset button and input preset number. The interface is shown as in Figure
4-41.
Now you can add this preset to one tour.
Figure 4-41
4.9.2 Activate Preset
In Figure 4-40, please input preset number in the No. blank, and click preset button.
4.9.3 Patrol setup (Tour Setup)
In Figure 4-38, click patrol button. The interface is shown as in Figure 4-42.Input preset number
and add this preset to a patrol (tour). For each patrol (tour), you can input max 80 presets.
To Next Page
