Without the protocol
For the ATM/POS without the protocol, the interface is shown as in Figure 7-77.
Source IP refers to host IP address that sends out information (usually it is the device host).
Destination IP refers to other systems that receive information.
Usually you do not need to set source port and target port.
There are total four groups IP. The record channel applies to one group (optional) only.
Six frame ID groups verification can guarantee information validity and legal.
Figure 7-77
Click the Data button you can set offset value, length, title according to your communication
protocol and data package.
7.8.7 Information
7.8.7.1 Version
The version interface is shown as in Figure 7-78.
Here you can view system hardware features, software version, release date and etc. Please
note the following information is for reference only.
