Qvis Izeus hdcvi dvr User Manual

© Copyright Qvis ®. All documentation rights reserved.
44
4.8.2 PTZ Setup
Note: The camera video should be in the current screen. Before setup, please check the
following connections are right:
 PTZ and decoder connection is correct. Decoder address setup is correctly.
 Decoder A (B) line connects with DVR A (B) line.
Boot up the DVR, input user name and password.
In the main menu, click setting, and then click Pan/Tilt Control button. The interface is shown
as in Figure 4-34. Here you can set the following items:
 Channel: select the current camera channel.
 Protocol: select corresponding PTZ protocol(such as PELCO-D)
 Address: default address is 1.
 Baud rate: select corresponding baud rate. Default value is 9600.
 Data bits: select corresponding data bits. Default value is 8.
 Stop bits: select corresponding stop bits. Default value is 1.
 Parity: there are three options: odd/even/none. Default setup is none.
Figure 4-34
After completing all the setting please click save button. Right click mouse (click “Fn” Button
in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure
4-35.
