Snapshot mode: There are two modes: Timing (Schedule) and activation. If you set
timing mode, you need to set snapshot frequency. If you set activation snapshot, you
need to go to Detect interface (Main menu->Setting-Detect) to set snapshot activation
operation.
Image size: Here you can set snapshot picture size.
Image quality: Here you can set snapshot quality. The value ranges from 1 to 6.
Snapshot frequency: It is for you to set timing (schedule) snapshot interval. The value
ranges from 1-7 picture(s) per second
Copy：After you complete the setup, you can click the Copy button to copy current setup to
other channel(s). You will seean interface is shown as in Figure 5-11. You will seecurrent
channel number is grey. Please check the number to select the channel or you can check
the box ALL. Please click the OK button in Figure 5-11 and Figure 5-8 respectively to
complete the setup. Please note, once you check the All box, you set same encode setup for
all channels. Audio/video enable box, overlay button and the copy button is shield. See
Figure 5-11.
Please highlight icon to select the corresponding function.
Figure 5-8
Figure 5-9
