Page 18 of 133
Version 3.0 Rev r000
Date 25-08-2010
Part No. 96000001
2.4 Sonic 2022 Dimensions and Weights
Component Dimensions (L x W x D) / Dry Weight
Receiver Module 276mm x 109mm x 190mm / 7.7kg
Projector 273mm x 108mm x 86mm / 3.3kg
Sonar Interface Module (SIM) 280mm x 170mm x 60mm / 2.4kg
Receive module and Projector mass in water 4.0kg (Fresh)
2.5 Sonic 2024/Sonic 2022 Electrical Interface
Item Specification
Mains Power 90 – 260 VAC; 45 – 65 Hz
Power Consumption (SIM and Sonar Head) 75 Watt (Sonic 2022: 54 Watt)
Power Consumption (Sonar Head Only) 50W avg.; 90W Peak (Sonic 2022: 35W avg.;
70W Peak)
Uplink/Downlink 10/100/1000Base-T Ethernet
Data Interface 10/100/1000Base-T Ethernet
Sync IN/OUT TTL
GPS Timing 1PPS; RS232 NMEA
Auxiliary Sensors RS232
Deck Cable Length 15 metre (optional to 50 metres)
Table 4: Electrical Interface
2.6 Sonic 2024/2022 Ping Rates
RANGE PING RATE
2 - 7 60.0
10 48.4
15 34.3
20 26.6
25 21.7
30 18.3
35 15.9
40 14.0
50 11.3
70 8.2
100 5.8
150 3.9
200 2.9
250 2.3
300 1.9
400 1.7
450 1.3
500 1.2
Table 5: Ping Rate table
WARNING
THE RECEIVE MODULE IS FILLED WITH
OIL THAT WILL FREEZE TO A SOLID AT
-10°C. DO NOT STORE OR USE THE
SYSTEM BELOW 0°C.
