Installation of Main Harness # 4000203 (Figures 9) (continued)
5. Gather all the items listed in the table in
figures 9.
6. Figures 9, 9a: Pass the main harness
(item 11) in the places indicated in the
figures and secure using two 4.8mm x 8"
long nylon tie wraps (item 8).
7. Figures 9b, 9c, 9d, 9e, 9f: Pass the main
harness (item 11) inside the tractor frame at
the locations shown in the figures and
secure with 4.8mm x 8" lg nylon tie wraps
(item 8).
