- 36 -
10.3. MEASUREMENT DATA PRINTOUT
Balance software allows the user to save data, relating to a measurement, on an external USB flash
drive.
The operation can be performed as follows:
• Plug a flash drive into USB port.
• Press button to abandon automatically started <IMPORT/EXPORT> option.
• Set parameter P4.2.1 <DEVICES/PRINTER/PORT> to <PENDRIVE> option.
• Return to the weighing mode.
• From this moment on, every single pressing of the button results with record of
measurement data (compatible with the settings for GLP0 PRINTOUT) in a text file, the text file
is automatically created by the balance software. The file name is: printout.txt.
• Press button to switch the balance off, next remove the pendrive from the port and read
the data on a computer. Keeping to this sequence of actions you are guaranteed that the data
is saved.
More data can be recorded in the same file. The balance software will add the data to the file that has
already been created on a flash drive. Consequently, you can continue saving measurements in the
same file once created.
CAUTION:
USB flash drive shall feature <FAT file system>.
11. WORKING MODES
− Weighings
− Parts Counting
− Checkweighing
− Dosing
− Deviations % in reference to mass of the standard
− Animal Weighing
− Density Determination of Solids
− Density Determination of Liquids
− Statistics
− Totalising
− Peak Hold
− Pipettes Calibration
In order to run a particular mode press
button, and select the mode from the list.
