18
Review Checklist
EXAMPLE:
Watering Restrictions are imposed;
You can only irrigate on even days of the
month from 10:00 PM until 6:00AM; lawn
maintenance occurs every Wednesday.
Lawns on Zones 1 & Zone 2 are newly
seeded and require a grow-in watering
period of 14 days at 3 minutes per cycle
for 8 cycles per calendar day to keep the
seed moist during the warmest part of
the day.
To meet site conditions, CONFIGURE
CONTROLLER as follows:
• Set Allowed Watering Days to Even Days
Of The Month
• Set Block Irrigation on Wednesdays
• Set 1st Watering Window from 10:00 PM
to 11:45PM
• Set 2nd Watering Window from
12:00AM (midnight) to 06:00AM
• Set Grow-In Watering Time from 9:00AM
until 5:00PM – Zone 1 &2 watering will
occur for the next 14 calendar days
for 3 minutes per cycle 8 times evenly
divided by the Grow-In Watering Time
(In this example 8 cycles in 8 hours = 1
cycle every hour)
Enter Site Data
Set Allowed Watering Days (selec t one)
Set Allowed Watering Times
Location by Zip Code
No Restrictions (OR)
Custom Day(s) of the week (OR)
Even Days of the Month (OR)
Odd Days of the Month - not 31st (OR)
Cyclical
Set 1st Watering Window
Set 2nd Watering Window
Set Grow-in Watering Window
Site Custom Data
5 Digit Site Zip Code (OR)
Site Latitude
Site Elevation
Monthly Avg. Wind Speed
Monthly Avg. Humidity
Days between Cycle
Beginning Date
Block Day Of Week
