Rain Master Irrigation Systems RME EAGLE User Manual
Appendix A Controller Displays Page 125
= Shown when REVIEW is pressed during a fault condition and
the problem is an over-current or short circuit in the station
field wiring. The faulty station(s) will be shown in the LED
lights.
= Shown when REVIEW is pressed during a fault condition and
the problem occurs when a station is activated but no water is
flowing. The faulty station(s) will be shown in the LED lights.
= Displayed at any time the controller is receiving commands or
information from the Rain Master iCentral web site.
A.2 DAYS/STATION NUMBER DISPLAY
The controller contains a secondary display which provides status on which Water Days have been
selected and which stations have been selected for each executing irrigation program. This display
consists of discrete Light Emitting Diodes (LED’s) and is located directly above the Prompt and
Message display, as depicted in Figure 12 - RME EAGLE Keyboard Configuration.
When the controller is in Automatic Mode the day of the week is displayed on the
DAYS/STATION NUMBER display.
WIRING
PROGRAM
NO FLOW
PROGRAM
WIRELESS
PROGRAM
