RME EAGLE User Manual Rain Master Irrigation Systems
Page 70 Chapter 6 Setup Key Operations
Or
If the sensor condition is Dry, the irrigation program(s) will operate normally. If the sensor
condition is Wet, no irrigation will take place on those configured program(s).
Additionally, when a program is scheduled to operate, an asterisk will appear in the leftmost
location in the display, if the external sensor has detected rain, or the external switch is Open.
NOTE: The external sensor is independent of the Rain Switch on the front of
the controller. Leave the front panel Rain Switch in the Automatic
Watering position.
EXAMPLE: To configure Program 4 for Sensor Mode,
Continue to Press: Until display indicates: CODE
Press:
Display will indicate:
Press:
The controller will return to the Automatic Mode.
SNSR-WET
PROGRAM
SNSR-DRY
PROGRAM
r 04:30
PROGRAM
SNSR1234
PROGRAM
SETUP
SNSR 123
PROGRAM
ENTER
QUIT
4
