Figure 2-8 Rear panel of the ISCOM2600-28G-DC
2.1.3 ISCOM2600-12X
ISCOM2600-12X-AC
Figure 2-9 shows the front panel of the ISCOM2600-12X-AC.
Figure 2-9 Front panel of the ISCOM2600-12X-AC
1
Power interface
2
Service interfaces (1–12) LEDs
3
Service downlink interfaces (1–8)
4
Service uplink interfaces (9–12)
5
SNMP interface, Console interface, and USB
interface
6
USB, MST, STK, SNMP, SYS, and PWR LEDs
7
Ground terminal
Figure 2-10 shows the rear panel of the ISCOM2600-12X-AC.
Figure 2-10 Rear panel of the ISCOM2600-12X-AC
ISCOM2600-12X-DC
Figure 2-11 shows the front panel of the ISCOM2600-12X-DC.
