ISCOM2600 (B) Series Product Description
4 Device installation
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
55
Power supply conditions
Table 4-2 lists power supply requirements on the operation of the ISCOM2600 series switch.
Table 4-2 Power supply requirements on operation
Parameter
Description
Power supply

AC power: the rated voltage is 220 VAC, and the voltage
range is 100–240 VAC.

DC power: the rated voltage is -48 VDC, and the voltage range
is -36 to -72 VDC.
Maximum power
consumption

ISCOM2600-28X: < 24

ISCOM2600-28G: < 24

ISCOM2600-12X: < 15

ISCOM2600-12G: < 15

ISCOM2600-28X-24F: < 55

ISCOM2600-28X-PWR
–
ISCOM2600-28X-PWR-DC/D: < 750 W
–
ISCOM2600-28X-PWR-AC_DC (when the DC power
supply is working): < 750 W
–
ISCOM2600-28X-PWR-AC_DC (when the AC power
supply is working): < 550 W
–
ISCOM2600-28X-PWR-AC/S: < 550 W
–
ISCOM2600-28X-PWR-AC/D: < 550 W

ISCOM2600-28X-PWH
–
ISCOM2600-28X-PWH-DC/D: < 750 W
–
ISCOM2600-28X-PWH-AC_DC (when the DC power
supply is working): < 750 W
–
ISCOM2600-28X-PWH-AC_DC (when the AC power
supply is working): < 550 W
–
ISCOM2600-28X-PWH-AC/S: < 550 W
–
ISCOM2600-28X-PWH-AC/D: < 550 W
The ISCOM2600 is supplied by multiple power supplies. Do remember to disconnect
all power inputs when powering off the device.
Grounding conditions
The ISCOM2600 series switch adopts common earthing mode, and the ground resistance
should be no greater than 1 Ω. Well grounding is the first guarantee for lightning protection
and anti-interference.
