Table 2-4 Parameters of the 10/100/1000 Mbit/s Ethernet electrical interface
Parameter
Description
Connector type
RJ45
Working mode

10/100/1000 Mbit/s auto-negotiation

Full/Half duplex auto-negotiation
Cable specifications

When the interface is working at 10/100 Mbit/s, we
recommend using the Cat 5 UTP cable.

When the interface is working at 1000 Mbit/s, we
recommend using the Cat 5e UTP or STP cable.
Standard
IEEE 802.3-compliant
2.2.2 Management interfaces
Table 2-5 lists types and usage of management interfaces on the ISCOM2600 series switch.
Table 2-5 Management interfaces
Interface
Description
Console (RJ45)
Local management and control interface. You can log in to the
ISCOM2600 series switch through Hyper Terminal to conduct local
management and configurations.
SNMP (RJ45)
10/100/1000BASE-T auto-negotiation electrical interface. You can
conduct out-of-band management on the ISCOM2600 series switch
through the SNMP interface.
RJ45 Console interface
Table 2-6 lists parameters of the RJ45 Console interface.
Table 2-6 Parameters of the RJ45 Console interface
Parameter
Description
Connector type
RJ45
Working mode
Duplex UART
Electrical feature
RS-232
Baud rate
9600 baud
SNMP interface
Table 2-7 lists parameters of the SNMP interface.
