Table 2-24 Parameters of 100 Mbit/s SFP optical modules
Model
Wavelength
(nm) (laser
type)
Receive
r type
Tx
optical
power
(dBm)
Minimum
overload
point
(dBm)
Extinctio
n ratio
(dB)
Rx
sensitivit
y (dBm)
Maximum
transmissi
on distance
(km)
USFP-03/M-
D-R/SW
1310
(LED/FP)
PIN
-20 to -
10
-10
10
-29
2
USFP-03/S1-
D-R/SW
1310(FP)
PIN
-15 to -
8
-8
10
-34
15
USFP-03/S2-
D-R/SW
1310
(FP/DFB)
PIN
-5 to 0
-8
8.2
-34
40
USFP-03/S3-
D-R/SW
1550(DFB)
PIN
-5 to 0
-10
10
-34
80
2.7.2 100 Mbit/s SFP electrical module
Table 2-25 lists parameters of 100 Mbit/s SFP electrical modules.
Table 2-25 Parameters of 100 Mbit/s SFP electrical modules
Model
Application
code
Auto-
negotiation
Data
interface
LoS
alarm
Maximum transmission
distance (m)
USFP-
FE/AN-R/SW
10/100BASE-
TX
Supported
SerDes
Supported
100
2.7.3 1000 Mbit/s SFP optical module
Table 2-26 lists parameters of 1000 Mbit/s SFP optical modules.
Table 2-26 Parameters of 1000 Mbit/s SFP optical modules
Model
Wavelength
(nm) (laser
type)
Receive
r type
Tx
optical
power
(dBm)
Minimum
overload
point
(dBm)
Extinctio
n ratio
(dB)
Rx
sensitivit
y (dBm)
Maximum
transmissi
on distance
(km)
USFP-Gb/M-
D-R/SW
850(VCSEL)
PIN
-9.5 to -
3
0
9
-17
0.55
USFP-Gb/S1-
D-R/SW
1310(FP)
PIN
-10 to -
3
-3
9
-21
15
USFP-Gb/S2-
D-R/SW
1550(DFB)
PIN
-3 to 2
-3
9
-21
40
USFP-Gb/S3-
D-R/SW
1550(DFB)
APD
-3 to 2
-9
9
-30
