Raisecom ISCOM2600 (B) Series - 1000 Mbit;S SFP Electrical Module; Gbit;S SFP+ Optical Module; Table 2-27 Parameters of 1000 Mbit;S SFP Electrical Modules; Table 2-28 Parameters of 10 Gbit;S SFP+ Optical Modules

Raisecom
ISCOM2600 (B) Series Product Description
2 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
45
Model
Wavelength
(nm) (laser
type)
Receive
r type
Tx
optical
power
(dBm)
Minimum
overload
point
(dBm)
Extinctio
n ratio
(dB)
Rx
sensitivit
y (dBm)
Maximum
transmissi
on distance
(km)
USFP-
Gb/EX-D-
R/SW
1550(DFB)
APD
0 to 5
-9
9
-30
120
2.7.4 1000 Mbit/s SFP electrical module
Table 2-27 lists parameters of 1000 Mbit/s SFP electrical modules.
Table 2-27 Parameters of 1000 Mbit/s SFP electrical modules
Model
Application
code
Auto-
negotiation
Data
interface
LoS
alarm
Maximum transmission
distance (m)
USFP-GE-
R/SW
1000BASE-T
Not supported
SerDes
Supported
100
USFP-GE/AN-
R/SW
10/100/1000
BASE-T
Supported
SGMll
Supported
100
2.7.5 10 Gbit/s SFP+ optical module
Table 2-28 lists parameters of 10 Gbit/s SFP+ optical modules.
Table 2-28 Parameters of 10 Gbit/s SFP+ optical modules
Model
Wavelen
gth (nm)
Recei
ver
type
Tx optical
power
(dBm)
Saturated
optical
power
(dBm)
Extincti
on ratio
(dB)
Rx
sensitivit
y (dBm)
Maximum
transmissio
n distance
(km)
USFP+-
192/M/SW
850
PIN
-7.3 to -1.0
-1.0
3.0
-11.1
0.3
USFP+-
192/S1/SW
1310
PIN
-8.2 to 0.5
0.5
3.5
-12.6
10
USFP+-
192/S2/SW
1550
PIN
-3.5 to 4.0
4.0
6.0
-16.0
40
USFP+-
192/S3/SW
1550
PIN
-1.0 to 4.0
4.0
9.0
-23.0
80
