Getting Started
R&S
®
FSVA3000/ R&S
®
FSV3000
41User Manual 1178.8520.02 ─ 01
<Type><variant>-<serial_number>
The serial number can be found on the rear panel of the instrument. It is the third part
of the device ID printed on the bar code sticker:
For example, FSV3007-123456
To change the computer name
1. Press the [Setup] key and then the "Network + Remote" softkey.
The current "Computer Name" is displayed in the "Network" tab.
2. Enter the new computer name.
3. Close the dialog box.
5.1.5.4 Changing the Windows Firewall Settings
A firewall protects an instrument by preventing unauthorized users from gaining access
to it through a network. Rohde & Schwarz highly recommends the use of the firewall on
your instrument. Rohde & Schwarz instruments are shipped with the Windows firewall
enabled and preconfigured in such a way that all ports and connections for remote
control are enabled.
For more details on firewall configuration, see the following Rohde & Schwarz White
Paper:
1EF96: Malware Protection Windows 10
Note that changing firewall settings requires administrator rights.
5.1.6 Configuring the Initial Instrument Settings
This section describes how to set up the R&S FSV/A initially. For further basic instru-
ment settings, see the R&S FSV/A User Manual.
Setting the Date and Time...................................................................................... 41
5.1.6.1 Setting the Date and Time
Assuming you have administrator rights, you can set the date and time for the internal
real time clock as follows:
Opening the Date and Time Properties dialog box
1. Press the [SETUP] key.
Preparing for Use

Table of Contents

Other manuals for R&S FSV3030

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the R&S FSV3030 and is the answer not in the manual?

R&S FSV3030 Specifications

General IconGeneral
Frequency Range10 Hz to 30 GHz
Input Impedance50 Ω
Input VSWR< 1.5:1
Input Power Level+30 dBm
Display1280 x 800 pixels
Power Supply100 V to 240 V, 50 Hz to 60 Hz
Resolution Bandwidth1 Hz to 10 MHz (1 Hz to 50 MHz with option)
Displayed Average Noise Level (DANL)-165 dBm (1 Hz RBW)
