General Instrument Setup
R&S
®
FSVA3000/ R&S
®
FSV3000
640User Manual 1178.8520.02 ─ 01
Generator Reference Level Offset
Defines a fixed offset to the reference level of the R&S FSV/A for the coupled signal
generator.
This setting requires the Coupling State to be enabled.
Remote command:
INSTrument:COUPle:GENerator:RLEVel:OFFSet on page 1151
12.10.4 How to Synchronize Parameters
Access: [SETUP] > "Parameter Coupling"
User-defined couplings allow you to couple parameters other than those available in
the "General" tab of the coupling manager. Thus, you can create highly customized
couplings between measurement channels.
Compared to the predefined couplings, user couplings do not necessarily have to syn-
chronize all active measurement channels. Instead you can define specific channels
that are synchronized with each other, in any combination, while other channels remain
independent.
How to use predefined parameter couplings
1. Select the [SETUP] key.
2. Select "Parameter Coupling".
3. In the "General" tab, set the parameter you want to synchronize over all measure-
ment channels to "On".
4. Close the dialog box.
How to create user-defined parameter couplings
1. Select the [SETUP] key.
2. Select "Parameter Coupling".
3. Select the "User Coupling" tab.
4. Select "Add New User Coupling".
5. From the "Channel 1" list, select the channels or type of channel to couple.
6. From the "Coupling Element 1" list, select the parameter or marker to couple for
the selected measurement channels.
To shorten the list and restrict it to a certain type of parameters, select a "Category"
first.
7. For Analog Demodulation channels and frequency markers only, select the individ-
ual windows (in the frequency domain) to couple.
8. To couple specific channels rather than all channels of a type:
Synchronizing Measurement Channel Configuration
