Getting Started
R&S
®
FSVA3000/ R&S
®
FSV3000
106User Manual 1178.8520.02 ─ 01
2. Select the "Keyboard" icon besides the entry field.
3. Enter the string you want to find.
If you enter several strings with blanks between, topics containing all words are
found (same as AND operator).
For advanced search, consider the following:
● To find a defined string of several words, enclose it in quotation marks. For
example, a search for "trigger qualification" finds all topics with exactly "trigger
qualification". A search for trigger qualification finds all topics that contain the
words trigger and qualification.
● Use "Match whole word" and "Match case" to refine the search.
● Use operators AND, OR, and NOT.
To close the Help window
► Select the "Close" icon in the upper right corner of the help window.
Or: Press the [ESC] key.
5.4.7 Remote Control
In addition to working with the R&S FSV/A interactively, located directly at the instru-
ment, it is also possible to operate and control it from a remote PC. Various methods
for remote control are supported:
●
Connecting the instrument to a (LAN) network (see Chapter 5.1.5, "Setting Up a
Network (LAN) Connection", on page 36)
●
Using the LXI browser interface in a LAN network
●
Using the Windows Remote Desktop application in a LAN network
●
Connecting a PC via the GPIB interface
How to configure the remote control interfaces is described in the User Manual.
SCPI Recorder
The R&S FSV/A now provides a SCPI Recorder tool that helps you create scripts for
remote control of the R&S FSV/A very quickly and easily.
For details, see Chapter 13.4, "Automating Tasks with Remote Command Scripts",
on page 686.
The R&S FSV/A is delivered with IECWIN installed, the auxiliary remote control tool
provided free of charge by Rohde & Schwarz.
For details on the IECWIN tool, see the "Network and Remote Control" chapter of the
R&S FSV/A User Manual.
Operating the Instrument
