Network and Remote Operation
R&S
®
FSVA3000/ R&S
®
FSV3000
685User Manual 1178.8520.02 ─ 01
Table 13-21: Instrument settings for emulation of 8566A/B, 8568A/B, 8594E; FSEA, FSEB, FSEM;
FSEK instruments
Model # of Trace
Points
Start Freq. Stop Freq. Ref Level Input Coupling
8566A/B 1001 2 GHz 22 GHz 0 dBm AC
8568A/B 1001 0 Hz 1.5 GHz 0 dBm AC
8560E 601 0 Hz 2.9 GHz 0 dBm AC
8561E 601 0 Hz 6.5 GHz 0 dBm AC
8562E 601 0 Hz 13.2 GHz 0 dBm AC
8563E 601 0 Hz 26.5 GHz 0 dBm AC
8564E 601 0 Hz 40 GHz 0 dBm AC
8565E 601 0 Hz 50 GHz 0 dBm AC
8594E 401 0 Hz 3 GHz 0 dBm AC
FSEA 500 0 Hz 3.5 GHz -20 dBm AC
FSEB 500 0 Hz 7 GHz -20 dBm AC
FSEM 500 0 Hz 26.5 GHz -20 dBm AC
FSEK 500 0 Hz 40 GHz -20 dBm AC
Note: The stop frequency indicated in the table may be limited to the corresponding
frequency of the R&S FSV/A, if required.
13.3 The IECWIN Tool
The R&S FSV/A is delivered with IECWIN installed, an auxiliary tool provided free of
charge by R&S. IECWIN is a program to send SCPI commands to a measuring instru-
ment either interactively or from a command script.
The R&S IECWIN32 tool is provided free of charge. The functionality may change in a
future version without notice.
IECWIN offers the following features:
●
Connection to instrument via several interfaces/protocols (GPIB, VISA, named pipe
(if IECWIN is run on the instrument itself), RSIB)
●
Interactive command entry
●
Browsing available commands on the instrument
●
Error checking following every command
●
Execution of command scripts
●
Storing binary data to a file
●
Reading binary data from a file
The IECWIN Tool
