R&S FSV3030 User Manual

Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
752User Manual 1178.8520.02 ─ 01
Example:
POW:TRAC 2
Assigns the measurement to trace 2.
Manual operation: See " Selected Trace " on page 162
14.5.3 Measuring the Channel Power and ACLR
All remote control commands specific to channel power or ACLR measurements are
described here.
See also Chapter 14.5.2, "Configuring Power Measurements", on page 748.
● Managing Measurement Configurations............................................................... 752
● Configuring the Channels......................................................................................754
● Defining Weighting Filters..................................................................................... 757
● Selecting the Reference Channel......................................................................... 759
● Checking Limits.....................................................................................................760
● General ACLR Measurement Settings..................................................................766
● Configuring MSR ACLR Measurements............................................................... 766
● Performing an ACLR Measurement......................................................................781
● Retrieving and Analyzing Measurement Results.................................................. 781
● Programming Examples for Channel Power Measurements................................ 784
14.5.3.1 Managing Measurement Configurations
The following commands control measurement configurations for ACLR measure-
ments.
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:PRESet............................................. 752
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:STANdard:CATalog?........................... 753
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:STANdard:DELete.............................. 753
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:STANdard:SAVE.................................753
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:PRESet <Standard>
This command loads a measurement configuration.
The measurement configuration for power measurements consists of weighting filter,
channel bandwidth and spacing, resolution and video bandwidth, detector and sweep
time.
Suffix:
<n>
.
Window
<m> Marker
<sb> irrelevant
Configuring and Performing Measurements
