R&S FSV3030 User Manual

Common Analysis and Display Functions
R&S
®
FSVA3000/ R&S
®
FSV3000
468User Manual 1178.8520.02 ─ 01
Display lines are only available in the Spectrum and (optional) Analog Demodulation
applications.
In the I/Q Analyzer application, lines are only available for measurements in the fre-
quency domain.
Access: "Overview" > "Analysis" > "Lines"
For remote operation, see Chapter 14.8.4, "Configuring Display and Limit Lines",
on page 1040.
● Display Lines.........................................................................................................468
● Limit Lines.............................................................................................................470
9.4.1 Display Lines
9.4.1.1 Basics on Display Lines
Display lines help you analyze a trace – as do markers. The function of a display line is
comparable to that of a ruler that can be shifted on the trace in order to mark absolute
values. They are used exclusively to visually mark relevant frequencies or points in
time (zero span), as well as constant level values. It is not possible to check automati-
cally whether the points are below or above the marked level values - use limit lines for
that task (see Chapter 9.4.2.1, "Basics on Limit Lines", on page 470).
Two different types of display lines are provided:
●
Two horizontal lines: "Horizontal Line 1" and "Horizontal Line 2".
These lines are continuous horizontal lines across the entire width of a diagram
and can be shifted up and down.
●
Four vertical lines: "Vertical Line 1" to "Vertical Line 4"
These lines are continuous vertical lines across the entire height of the diagram
and can be shifted left and right.
Lables
Each line is identified by one of the following abbreviations in the diagrams:
●
H1: "Horizontal Line 1"
●
H2: "Horizontal Line 2"
●
V1: "Vertical Line 1"
●
V2: "Vertical Line 2"
●
V3: "Vertical Line 3"
●
V4: "Vertical Line 4"
9.4.1.2 Display Line Settings
Access: "Overview" > "Analysis" > "Lines" > "Display Lines"
Display and Limit Lines

R&S FSV3030 Specifications

General

Frequency Range	10 Hz to 30 GHz
Input Impedance	50 Ω
Input VSWR	< 1.5:1
Input Power Level	+30 dBm
Display	1280 x 800 pixels
Power Supply	100 V to 240 V, 50 Hz to 60 Hz
Resolution Bandwidth	1 Hz to 10 MHz (1 Hz to 50 MHz with option)
Displayed Average Noise Level (DANL)	-165 dBm (1 Hz RBW)
