Preparing for Use
R&S
®
SMW200A
21Getting Started 1412.9220.02 ─ 21
To start the R&S SMW
Starting the R&S SMW requires that it is connected and turned on.
► At the front panel, press the [On/Standby] key briefly.
The instrument boots the operating system and starts the instrument firmware.
After booting, the instrument is in the state before the last power off (standby
or ready), indicated by the color of the [On/Standby] key's LEDs:
● Green: the R&S SMW is running and ready for operation.
All modules are power-supplied.
● Orange: the R&S SMW is in standby mode (main AC power switch is in
position "I").
The standby power mode keeps the power switch circuits and the oven-
controlled crystal oscillator OCXO active. In this state, it is safe to switch
off the AC power and disconnect the instrument from the power supply.
To switch between standby and ready state, briefly press the [On/Standby]
key.
If a previous session was terminated regularly, the instrument uses the last setup
with the relevant instrument settings.
► To set up a new configuration, press the [PRESET] key to return the instru-
ment to its defined reset/preset state.
To customize the start settings, e.g. to recall previously saved settings:
●
Use the [SAVE/RCL] function or
●
Define the [USER] key.
Putting into Operation
