R&S SMW200A User Manual

Instrument Tour
R&S
®
SMW200A
30Getting Started 1412.9220.02 ─ 21
6 = Navigation controls
7 = I/Q input connectors
8 = USB connectors
9 = SENSOR connector
10 = USER x input/output connectors
11 = RF A/RF B output connectors
5.1.1 Touchscreen
The block diagram and the most important settings are displayed on the screen
on the front panel. Additionally, the screen display provides status and setting
information and allows you to quickly reconfigure the signal flow. The screen is
touch-sensitive, offering an alternative means of user interaction for quick and
easy handling of the instrument.
Figure 5-2: Touchscreen elements
Front Panel Tour
