1 = Status bar (frequency and level display)
2 = Block diagram
3 = Taskbar/softkey bar
A touchscreen is a screen that is touch-sensitive. It reacts in a specified way
when a particular element on the screen is tapped by a finger. Any user interface
element that can be clicked by a mouse pointer can also be tapped on the screen
to trigger the same behavior.
Using the touchscreen, the following tasks (among others) can be performed by
the tap of your finger:
●
Changing a setting
●
Selecting new settings
●
Scrolling through the list of parameters
●
Saving or recalling settings
●
Routing the signal flow
●
Opening and closing dialogs
See also Chapter 6, "Trying Out the Instrument", on page 47.
To imitate a right-click by mouse using the touchscreen, for example to
open a context-sensitive menu for a specific item, touch and hold the
screen for about 1 second.
