12 SPECIFICATIONS
12.4 MACHINE SPECIFICATION ____________________________________________
Frame construction: Heavy duty steel chassis with formed steel frame rails.
Cutter Deck Drive: Three individual hydraulic motors with dual belt final drive.
Transmission: Hydrostatic closed loop parallel cross series SureTrac system. Variable displacement
piston pump. Front high torque fixed displacement piston wheel motors. Full time auto
4WD forward, on demand 4 WD in reverse.
Speeds:
Cutting: 0 - 12 km/h (0 - 7.5 mph) Forward
0 - 6.4 km/h (0 - 4 mph) Reverse
Transport: 0 - 25 km/h (0 - 15.5 mph) Forward
0 - 6.4 km/h (0 - 4 mph) Reverse
Creep 0 - 8 km/h (0 - 5 mph) Forward
0 - 5 km/h (0 - 3.1 mph) Reverse
Steering: Q-AMP
®
variable rate hydrostatic powered equal displacement cylinders to rear wheels.
Cooling System: Side by side pressurised radiator/hydraulic oil cooler; 7.8 litre (8.25 qt).
Reversing Fan: Hydraulically driven, temperature controlled reversible engine fan. Reverses automatically
or on demand to clear air intake screens.
Ground pressure: Depends on the tyre pressures and the accessories installed.
Brakes: Hydrostatic braking with wet disc parking brakes on the front wheels.
Battery: BBMS 369 70 Amp Hours, 570 CCA
Tie Down Points: Rated at 12.3 kN when strapped down at 45° +/- 5°.
The tie down rating was calculated using measurements according to the requirements of
BS ISO 15818:2017.
Cab Climate Control:
Technical data
Air conditioning system
Heating performance 6.0 kW
Cooling performance 4.5 kW
Refrigerant R 134A
Recommended refrigerant level 800 g
Operating voltage 12 V
Power consumption, clutch max.49W
Refrigerant oil 135 cc
Refrigerant oil - in the compressor 50 cc
